Dimensions

        approx. 200 x 42 x 127 mm



    Weight

        approx. 340g



    Power supply

        12 V DC nom. / 300 mA



    AF frequency response

        50 to 16.000 Hz (–3 dB)



Transmitter



    Dimensions

        approx. 71 x 96 x 28 mm



    Weight

        approx. 95g



    Power supply

        2 AA size batteries. 1.5 V



    Adjustment Range Transmitter

        0 to -30 dB. adjustable in 10 dB steps



    Microphone

        condenser



    THD. total harmonic distortion

        ≤ 0.9%



    Pick-up pattern

        omni-directional



    Signal-to-noise ratio

        ≥ 103 dBA



    RF output power

        10 mW



    Switching bandwidth

        up to 24 MHz



    Operating time

        approx. 10 hrs



    Modulation

        wideband FM



    Output voltage

        ‘1/4 (6.3 mm) jack socket (unbalanced): +6 dBu. XLR socket (balanced): +12 dBu



    Housing

        rugged ABS housing



    Diversity reception

        antenna switching diversity via internal antennas



    Frequency

        8 frequency banks. each with up to 10 factory-preset channels



    Frequency range

        A: 548-572 MHz. GB: 606-630 MHz

        B: 614-638 MHz. C: 766-790 MHz

        D: 794-806 MHz

        E: 821-832 MHz. 863-865 MHz

        K: 925-937.5 MHz



    Sensitivity

        < 3 μV at 52 dB(A)rms S/N



    SPL for peak deviation

        130 dB



    Squelch

        adjustable from 3 dBμV to 28 dBμV (combined with pilot tone)



    Synchronization

        2.4 GHz. Low Power OQPSK (only active during synchronization)



    Input sensitivity

        1.5 mV / Pa



    Audio adjustment range

        45 dB. adjustable in 5-dB steps



    Line / Mic level

        20 dB. switchable



    Temperature Range

        operation: 0°C to +40°C. storage: –20°C to +70°C



    Receiver Principle

        double superheterodyne
